Measuring gas |
Combustible gas, toxic gas |
|
Sample method |
Diffuse naturally |
|
Power |
DC24V±6V, ≤3.0W |
|
Response time |
LEL: T90≤15s Toxic gas: T90≤30s |
|
Electrical output |
4-20mA, Hart, RS485-RTU |
|
Relays |
For 1st alarm, 2nd alarm, Fault ; SPST contacts rated 3A 30Vdc or 3A 250Vac |
|
Operation by |
Magnetic bar or IR remote control |
|
Measuring gas |
Combustible gas, toxic gas |
|
Sample method |
Diffuse naturally |
|
Power |
DC24V±6V, ≤3.0W |
|
Response time |
LEL: T90≤15s Toxic gas: T90≤30s |
|
Electrical output |
4-20mA, Hart, RS485-RTU |
|
Relays |
For 1st alarm, 2nd alarm, Fault ; SPST contacts rated 3A 30Vdc or 3A 250Vac |
|
Operation by |
Magnetic bar or IR remote control |
|
State indication |
Yellow--Fault, Red--Alarm, Green--Power |
|
Operating temperature |
LEL: -40～70℃ Toxic: -20～50℃ |
|
Humidity |
≤95%RH (no condensation) |
|
Ambient pressure |
86KPa～106KPa |
|
Ex grade |
II 2GD
Ex db IIC T6 Gb
Ex tb IIIC T80℃ Db
-40℃≤Ta≤+60℃ |
|
Ingress protection |
IP66/67 |
|
Enclosure material |
Stainless steel |
|
Cable entry |
NPT3/4 |
|
Dimensions |
130mm x 209mm x 116mm |
|
Weight |
About 5.5kg |
